Eton 7-360 7" HEXACone Bass/Midrange
Click to enlarge
Price: $145.50 (each)
Product ID : 7-360
Manufacturer: Eton
Weight: 4.62 lbs
E-mail to a friend | Add To Wish List

Purchase

  • 10% off for 10+

Description

Eton 7-360 7" HEXACone Bass/Midrange

7" diameter high-end bass-midrange driver utilizing a "Hexacone" sandwiched diaphragm, offering precise & highly detailed sound reproduction as well as excellent imaging. ETON 7-360/37 HEX features high power handling and excellent dynamic behaviour due to it"s large and linear cone excursion. This driver is highly recommended as a bass-midrange driver in high-end 2-way loudspeaker enclosures and is especially suitable for bass-reflex enclosures of 15L volume upwards. A woofer / midrange speaker with inverse surround, that is suitable for use in closed and also open constructions (bass reflex etc.). The typical characteristic of this chassis is a neutral, warm and voluminous reproduction that above all provides for a full sound in the fundamental tone and bass range.

Recommended Enclosure:

0.35 cu ft vented (single 1.5" diameter straight vent x 4.725" length) F3 ~84 Hz.

0.50 cu ft vented (single 2" diameter straight vent x 4.1" length) F3 ~ 55

  • No coloration
  • Excellent sound quality
  • Rubber surround
  • Aluminum diecast basket
  • Flange 186mm
  • Cut-out 160mm
  • Depth 83mm
  • Znom 8 ohm
  • Re 5.6 ohm
  • Le@1kHz 0.64 mH
  • fs 43 Hz
  • Qms 2.74
  • Qes 0.42
  • Qts 0.37
  • Mms 18 g
  • Cms - mm/N
  • Sd 137 cm2
  • BL 7.8 N/A
  • Vas 20.0 ltrs
  • Xmax 3.0 mm peak
  • VC Ø 37 mm
  • Sensitivity 1W / 1m 89 dB
  • Nom. Power DIN 100 W
