Eton 7-360 7" HEXACone Bass/Midrange
Click to enlarge
|
 Price: $145.50 (each)
Product ID : 7-360
Manufacturer: Eton
Weight: 4.62 lbs
Purchase |
Description
Eton 7-360 7" HEXACone Bass/Midrange
7" diameter high-end bass-midrange driver utilizing a "Hexacone" sandwiched diaphragm, offering precise & highly detailed sound reproduction as well as excellent imaging. ETON 7-360/37 HEX features high power handling and excellent dynamic behaviour due to it"s large and linear cone excursion. This driver is highly recommended as a bass-midrange driver in high-end 2-way loudspeaker enclosures and is especially suitable for bass-reflex enclosures of 15L volume upwards. A woofer / midrange speaker with inverse surround, that is suitable for use in closed and also open constructions (bass reflex etc.). The typical characteristic of this chassis is a neutral, warm and voluminous reproduction that above all provides for a full sound in the fundamental tone and bass range.
Recommended Enclosure: 0.35 cu ft vented (single 1.5" diameter straight vent x 4.725" length) F3 ~84 Hz.
- No coloration
- Excellent sound quality
- Rubber surround
- Aluminum diecast basket
- Flange 186mm
- Cut-out 160mm
- Depth 83mm
- Znom 8 ohm
- Re 5.6 ohm
- Le@1kHz 0.64 mH
- fs 43 Hz
- Qms 2.74
- Qes 0.42
- Qts 0.37
- Mms 18 g
- Cms - mm/N
- Sd 137 cm2
- BL 7.8 N/A
- Vas 20.0 ltrs
- Xmax 3.0 mm peak
- VC Ø 37 mm
- Sensitivity 1W / 1m 89 dB
- Nom. Power DIN 100 W
