SB Acoustics SB17MFC35-8 6" Polypropylene Cone Woofer - 8 ohm
Manufacturer Specifications PDF
- Vented cast aluminium chassis for optimum strength and low compression
- Mineral filled PP-cone made in-house
- Soft low damping rubber surround for improved transient response
- Non-conducting fibre glass voice coil former for minimum damping
- Extended copper sleeve on pole piece for low inductance and low distortion
- CCAW voice coil for reduced moving mass
- Long life silver lead wires
- Vented pole piece for reduced compression
Suggested Boxes:
In a 0.35 cubic foot sealed box your F3 is about 75Hz.
In a 0.5 cubic foot box with a 1.5" diameter vent by 6" long your F3 is about 50Hz.
In a 0.75 cubic foot box with a 2" diameter vent by 7" long your F3 is about 45Hz.
