Hi-Vi M5N 5" Wide Range Woofer, Copper Color Cone

Hi-Vi M5N 5" Wide Range Woofer, Copper Color Cone
Click to enlarge
Price: $21.50

Purchase

  • Buy 10 - 10,000 and get an additional 10 % off
Manufacturer: HiVi
Product ID : m5n
Weight: 3.75 lbs
Manufacturer: HiVi
E-mail to a friend

Description

Hi-Vi M5N 5" Aluminum/Magnesium Alloy Woofer, Copper Color Cone, Shielded Magnet

Nominal Impedance (Z)(Ω) : 8
Resonance Frequency (Fs)(Hz) : 47
Nominal Power Handling (Pnom)(W) : 35
Max Power Handling (Pmax)(W) : 70
Sensitivity (2.83v/1m)(dB) : 87
Weight (M)(Kg) : 1.5
VC Diameter (mm) : 25
DC (Re)(Ω) : 6.5
VC Length (H)(mm) : 10.4
VC Former : SV
VC Frame : Kapton
Magnet System : Shielded
Magnet Former : Ferrite
Force Factor (BL)(N/A) : 7.5
Gap Height (He)(mm) : 5.0
Linear Excursion (Xmax)(mm) : 2.7
Suspension Compliance (Cms)(uM/N) : 1051
Mechanical Q (Qms) : 6.51
Electrical Q (Qes) : 0.37
Total Q (Qts) : 0.35
Moving Mass (Mms)(g) : 10.7
Effective Piston Area (Sd)(m2) : 0.0087
Equivalent Air Volume (Vas)(L) : 11.3
Cabinet Type : Vented
Recommended Box Volume(Vb)(L) : 10
Tuning Frequency(Fb)(Hz) : 50
-3dB Cut-Off Frequency(F3)(Hz) : 48

Incorporated into the Diva line of loudspeakers manufactured by Swans the M5N earned the Exceptional Value Award at The Home Entertainment Show 2000.

In 1999, Swans manufactured M5N woofer with original and beautiful appearance, which is suitable for digital audio and sound signal linear loudspeaker system, which is dynamic and with low distortion. This design has laid another landmark of Swans loudspeaker.

Advanced alloy (magnesium/aluminum) cone, coated with special damping material, having good rigidity and dynamic stability, improving the sonic features of the driver; High power handling, heat-resistant Kapton Voice coil former and heat-resistant SV voice coil wire; Finite Element Analysis for shielded magnetic system with long-throw linear excursion design.

Hi-Vi Symmetric Motor Drive (SMD) technology makes the voice coil into a symmetrical driving magnetic field, thus acquiring symmetrical driving force, reducing voice coil inductance and back electromotive force modulation, improving the controllability of the speakers; Low distortion degree.

Finite Element Analysis for flat & rigid iron frame, prevent the parasitic structural resonances.

Using leading technology of Small/Thiele parameters

M5N can be used as a bass or midrange in a two-way bookshelf speaker system; or used as a main speaker, center channel speaker, surround speaker, or subwoofer in a home theatre system; it can also be used in multimedia speaker systems.

Comment on Facebook

Product Reviews

Login or Register to write a review.
Reviewed by jcp22@mindspring.com
08/28/2016 - 08:47:27 PM
Wonderful driver for the price
For my truck speaker system I needed a driver that would perform very well and require a very small sealed cabinet to keep the overall box size down, and that would mate well with the Peerless tweeter. See the video: https://www.youtube.com/watch?v=DJLWIVTk-HM. They sound wonderful and I enjoy them every day. Great choice for any system.
Reviewed by mperryman
mperryman bought "Hi-Vi M5N 5" Wide Range Woofer, Copper Color Cone" on our website
08/21/2013 - 06:14:58 PM
Hi-Vi M5N wide Range Woofer
I installed a pair of these into a set of Mirage bookshelf cabinets ,wow
man it was a perfect x-over match the sound was full and open
with clarity . Look at this speaker for all small/ full range projects,
