ScanSpeak 22W/8851T-00 8"Revelator Woofer

ScanSpeak 22W/8851T-00 8"Revelator Woofer
Click to enlarge
Price: $341.40


  • Buy 10 - 10,000 and get an additional 10 % off
Manufacturer: ScanSpeak
Product ID : 22w_8851t
Weight: 11.00 lbs
Manufacturer: ScanSpeak
E-mail to a friend


ScanSpeak 22W/8851T-00 8" Revelator Woofer

The Scan-speak 22W/8851T is a new addition to the Revelator line. This robust 8" woofer was designed to provide deep and accurate bass in a small enclosure. This woofer features a 2" voice coil on a titanium former, a low loss linear suspension and symmetric drive motor. The deep set hard paper cone is attached to the frame with a minimal reflection rubber surround. The 9mm X-max insures good linear travel.

Madisound recommends:
1.2 cubic foot enclosure with a 2.5"Ø vent by 8" long for and F3 of 38Hz.
1.5 cubic foot enclosure with a 3"Ø vent by 9" long for and F3 of 34Hz.

  • Outside diameter: 222mm
  • Cut out: 194mm
  • Depth: 111mm
  • 25.4mm = 1" = 2.54cm
