SB Acoustics SB29NRX75-6 10" Woofer

SB Acoustics SB29NRX75-6 10" Paper Cone Woofer- 6 ohm

This 10" woofer features a proprietary composition paper cone with a special coating. The rubber surround has been carefully chosen to properly dampen the cone movement. The open-structure cast frame has been specially engineered for minimum reflections and good air flow.

SB29NRX75-6 + SB12NRXF25-4 + SB29RDC-COOO-4 3-way Passive Crossover Design
SB29NRX75-6 + H1262 + SB29RDC-C000-4 3-way Passive Crossover Design
SB29RNX75+ H1571 + H1212 3way Passive Crossover Design

Specifications PDF: SB29NRX75-6 PDF

• Hard paper cone
• Low damping SBR surround
• Open structure cast frame for reduced reflections
• Raised spider
• 75mm Voice Coil diameter
• Frequency range 22Hz to 900Hz
• Gasket

Dimensions:

• Flange diameter: 290mm
• Cut out diameter: 247mm
• Depth: 119mm
• Flange thickness: 10mm
• Screw mounting diameter: 268mm
• Screw hole size: 5.5mm

Suggested Alignments:

• Sealed box of 0.8 cubic feet for and F3 of 48Hz
• Vented box of 2.0 cubic feet with a 3" diameter vent by 12" long for an F3 of 28Hz.
