SB Acoustics SB12PFC25-4-COAX 4" Coaxial- 4 ohms
Manufacturer: SB Acoustics
Product ID: SB12PFC25-4-COAX
Price:
$63.60
Overview
SB Acoustics SB12PFC25-4-COAX 4" Coaxial- 4 ohm
SB Acoustics SB12PFC25-4-COAX 4" Coaxial- 4 ohm
PDF Spec Sheet
- Vented reinforced plastic chassis
- Proprietary cone material with natural fibers made in-house
- Soft low damping rubber surround for improved transient response
- Optimized motor system
- Non-resonant long life lead wires
- Compact large surround dome tweeter
Crossover: For this SB12 you'd use the first row- the 5.6mfd and a 15mfd in series.
Crossover Schematic PDF
Suggested Box Alignments:
Sealed box of about 0.1 cubic feet (2.8 liters) for F3 of 145Hz
Vented box of 0.1 cubic feet (2.8 liters) with 1" diameter vent by 4" long for F3 of 70Hz
