WBT-0110Ag-W nextgen Silver Signature - White

Price: $97.00

Purchase

The selected item is out of stock, please select a different item or combination

Manufacturer: WBT

Product ID : wbt-0110ag-w

Weight: 0.11 lbs

Manufacturer: WBT

E-mail to a friend

Please complete this form.
All fields are required.

Your name

Your email address

Your friend's name

Your friend's email

Captcha

Please enter CAPTCHA

Description

WBT-0110Ag-W nextgen Silver Signature - White

Spec sheet: WBT - 0110 RCA Plug nextgen

Passivated pure fine silver contacts. The body is constructed of Ultramid, while the negative contact uses Dyneon. The Barrel is comprised of Al/Mg alloy for improved rejection of EMI. With a characteristic impedance of 75 ohms, the WBT-0110 makes the perfect match for digital audio and video. The maximum size conductor that can be used is 1.5mm² / 16-17 AWG. Maximum diameter of cable with dielectric is 9mm² / 0.354 inches². Connector body available in nine different colors for multichannel identification. The barrel is offered in cobalt blue only.

Soldering required. Consider using WBT-0820 silver solder and a WBT-0488 Torx key.

Characteristic impedance: 75 ohms

For cable up to 9 mm dia.
