Satori TW29RN-B Ring Dome Tweeter with Neodymium Motor - Black, 4 ohm

Satori TW29RN-B Ring Dome Tweeter with Neodymium Magnet System - Black Face Plate- 4 ohm- 96 dB

Spec Sheet PDF

"N" Neodymium version

Very clean and natural sounding, the TW29RN is a premium ring dome tweeter offered in the Satori line by SB Acoustics. This tweeter has many advanced technology features that culminate in very detailed and low distortion output, a perfect choice in any high end system. 4 ohm version. Features include a high saturation neodymium motor system with T-shaped pole piece for lower distortion and 2-part aluminum faceplate with integrated mechanical decoupling. Upgraded version of the well-regarded TW29R.  Black Face Plate- 4 ohm- 96 dB

• Very high efficiency of 96dB
• Non-resonant diaphragm design for minimum high frequency break-up
• Two part aluminum faceplate with integrated mechanical decoupling
• Dual balanced compression chambers for improved dynamics
• Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
• High saturation neodymium motor system with T-shaped pole piece for lower distortion
• Non-reflective cast alumimum chamber with optimized damping for improved dynamics
• Shallow flow optimized magnet structure for optimum coupling to rear chamber
• CCAW voice coil for low moving mass
• Long life silver lead wires
• Low resonance frequency for extended range
