SB Acoustics SB12PAC25-4 4" Aluminum Cone Woofer

SB Acoustics SB12PAC25-4 4" Aluminum Cone Woofer- 109mm squarish- 4 ohm

Low Q, could be used in small vented box (see below). Great for a tiny 2-way!

SB12PAC25-4 PDF

• Vented reinforced plastic chassis
• Anodised aluminium cone
• Low damping rubber surround
• Large vented motor system
• Long stroke linear suspension
• Light weight CCAW voice coil
• Non-conducting fibreglass coil former
• Non-resonant long life lead wires

Sealed box of 0.05 to 0.1 cubic feet should give you a 3dB down point of about 140Hz.

Vented box of 0.1 cubic feet with a 1" diameter vent by 4" long will give you F3 of about 70Hz.

Vented box of 0.2 cubic feet with a 1.5" diameter vent by 4.25" long will give you F3 of about 59Hz.
