MarkAudio MA200M 8" 'Multi Midnight' Copper Color Cone Full Range

MarkAudio MA200M 'Multi Midnight' Copper Color Magnesium Alloy Cone 8" Full Range- 224mm- 8 ohm

Spec Sheet PDF

The MA200M Multi is a new design 8-inch high-fidelity driver for multi-use applications and high-volume speaker projects. The driver retains Markaudio’s unique design concept, style, and functionality, producing real bass combined with full-range frequency output. The MA200M Multi is a testament to Markaudio’s commitment to versatility.

• Biggest size Markaudio driver
• Completely new design, multi-use applications
• Aerospace-grade aluminum magnesium mix alloy cone
• Operating range to 20KHz
• Balanced low-frequency and high frequency
• Advanced low-distortion motor design
• Long-stroke, low resonance frequency
• Cast aluminum chassis optimizes sound wave emittance and airflow

The cone is made from a high-strength, aerospace-grade aluminium magnesium mixed alloy, designed to cope with high bending stress loads. The material thickness is carefully balanced to maximize low-frequency load capacity while retaining excellent performance at higher frequencies. Combined with the long-stroke suspension and low-distortion motor, provides a low resonant frequency, medium Q, and an air volume compliance to around 65 liters. The driver is optimized for larger enclosures delivering a smooth extended range from 30Hz to above 20KHz in suitable box designs.

The chassis is designed with rounded angles to improve sound wave emittance and optimized airflow. The MA200M Multi driver represents high performance with affordability. It provides custom builders with broad operational flexibility in traditional full-range or wide-range mid-bass, the MA200M Multi is ideal for use in high-fidelity, home-theatre, and commercial A/V applications. It’s ideal for a wide choice of enclosure types. Markaudio provides users with high-quality listening experiences by continuing to develop advanced mechanically engineered audio drivers at affordable prices.

The MA200M can be used in a variety of enclosure types including vented box. Please see MA200M Project Plans Page. We've also linked more plans below.

Use QC205R & QC205B if not soldering.

• MA200-M-CHN50 MTM
• MA200-M Bessel aligned sealed box standmount
• MA200-M Butterworth aligned sealed box standmount
• MA200-M DCR standmount
• MA200-M Keele aligned EBS vented box
• MA200-M large vented box standmount
• MA200-M medium vented box standmount
• MA200-M Pi-Align vented box standmount
• Pensil MA200-M-metric
• Pensil MA200 -M-imperial
• Mauna Kea MA200 -M MLTL
• MA200M Floorstanding DCR
• MA200-M linear quadrupole
• Syncerus Antiquus MA200M MLTL
• Margaret MA200-M traditional vented box standmount
• MAOP5+MA200M standmount

RE 6.8 Ohms FS 33.0003 Hx SD 0.0206 m2 VAS 65.1957 L CMS 1.0990 mm/N MMD 19.4093 g MMS 21.1652 g BL 8.5460 T/M QMS 2.239 QES 0.4086 QTS 0.3455 RMS 1.96 WM SPL 90.26 dB POWER (NOMINAL) 50 Watts X MAX 9 mm (one way) COLOUR Midnight Copper
