Markaudio MA200M 8" 'Multi Stealth' Grey Color Cone Full Range

MarkAudio MA200M 8" 'Multi Stealth' Grey Color Magnesium Alloy Cone Full Range- 224mm- 8 ohm

Spec Sheet PDF

The MA200M Multi is a new design 8-inch high-fidelity driver for multi-use applications and high-volume speaker projects. The driver retains Markaudio’s unique design concept, style, and functionality, producing real bass combined with full-range frequency output. The MA200M Multi is a testament to Markaudio’s commitment to versatility.

• Biggest size Markaudio driver
• Completely new design, multi-use applications
• Aerospace-grade aluminum magnesium mix alloy cone
• Operating range to 20KHz
• Balanced low-frequency and high frequency
• Advanced low-distortion motor design
• Long-stroke, low resonance frequency
• Cast aluminum chassis optimizes sound wave emittance and airflow

The cone is made from a high-strength, aerospace-grade aluminium magnesium mixed alloy, designed to cope with high bending stress loads. The material thickness is carefully balanced to maximize low-frequency load capacity while retaining excellent performance at higher frequencies. Combined with the long-stroke suspension and low-distortion motor, provides a low resonant frequency, medium Q, and an air volume compliance to around 65 liters. The driver is optimized for larger enclosures delivering a smooth extended range from 30Hz to above 20KHz in suitable box designs.

The chassis is designed with rounded angles to improve sound wave emittance and optimized airflow. The MA200-M Multi driver represents high performance with affordability. It provides custom builders with broad operational flexibility in traditional full-range or wide-range mid-bass, the MA200M Multi is ideal for use in high-fidelity, home-theatre, and commercial A/V applications. It’s ideal for a wide choice of enclosure types. Markaudio provides users with high-quality listening experiences by continuing to develop advanced mechanically engineered audio drivers at affordable prices.

The MA200M can be used in a variety of enclosure types including vented box. Please see MA200M Project Plans Page. We've also linked more plans below.

Use QC205R & QC205B if not soldering.

• MA200-M-CHN50 MTM
• MA200-M Bessel aligned sealed box standmount
• MA200-M Butterworth aligned sealed box standmount
• MA200-M DCR standmount
• MA200-M Keele aligned EBS vented box
• MA200-M large vented box standmount
• MA200-M medium vented box standmount
• MA200-M Pi-Align vented box standmount
• Pensil MA200-M-metric
• Pensil MA200 -M-imperial
• Mauna Kea MA200 -M MLTL
• MA200M Floorstanding DCR
• MA200-M linear quadrupole
• Syncerus Antiquus MA200M MLTL
• Margaret MA200-M traditional vented box standmount
• MAOP5+MA200M standmount

RE 6.8 Ohms FS 33.0003 Hx SD 0.0206 m2 VAS 65.1957 L CMS 1.0990 mm/N MMD 19.4093 g MMS 21.1652 g BL 8.5460 T/M QMS 2.239 QES 0.4086 QTS 0.3455 RMS 1.96 WM SPL 90.26 dB POWER (NOMINAL) 50 Watts X MAX 9 mm (one way) COLOUR Stealth Grey
