ScanSpeak Revelator D2908/716000 TPCD Dome Tweeter- 8 ohm

ScanSpeak Revelator D2908/716000 TPCD Dome Tweeter- 8 ohm- 120mm faceplate- Titanium VC Former

TPCD technology

Spec Sheet PDF

Audio Xpress Article

Scan Speak suggests the D2908/716000 as a possible replacement for discontinued D2908/714000.

TPCD (Thin-Ply Carbon Diaphragm) dome, applying the latest technology tweaks in order to realize the mechanical properties of carbon fiber that make the tweeter a true Scan-Speak driver. The ultra lightweight, very high stiffness and very well controlled breakup patterns minimize distortion and maximize linearity, offering natural and – true to live – sound reproduction. The Revelator Tweeters' large roll surround and TPCD dome diaphragm technology represent a breakthrough in overall performance with outstanding off-axis response and low distortion, high output capability and low resonance frequency. Additional enhancements have been made to reduce distortion and power compression, such as large neodymium magnet systems for high sensitivity and a careful design to optimise airflow in the chambers.

  Size: 2.6 cm   Fs: 534 Hz   Re: 5.7 Ω   Qt: 0.47   Sensitivity: 92 dB   VAS: 0.02 ltr.   Sd: 7 cm²   Bl: 3.6 Tm
