Satori TW29BN-B Beryllium Dome Tweeter - Black Flange
Manufacturer: SB Acoustics
Product ID: TW29BN-B
Price:
$437.30
Overview
Satori TW29BN-B Beryllium Dome Tweeter with Neodymium Magnet System - Black Face Plate- 104mm- 4 ohm- 95dB (also called TW29BN-B-4)
High SPL neodymium version
Satori TW29BN-B Beryllium Dome Tweeter with Neodymium Magnet System - Black Face Plate- 104mm- 4 ohm- 95dB (also called TW29BN-B-4)
High SPL neodymium version
Link to TW29BN pdf download.
The new Satori Beryllium dome tweeter has arrived! Beryllium is known for its open and spatial sound, often described as holographic. The self damping properties of Beryllium allow for an extended response without a huge spike in the response at higher frequencies seen in most metal dome tweeters. All dome materials have a different tonal and spatial presentation. Beryllium has a real positive difference, providing a experience unlike all other dome materials.
Special Features:
Beryllium is a toxic material. Should you ever break the dome, do not touch the pieces with your bare hand.
High SPL neodymium version
Link to TW29BN pdf download.
The new Satori Beryllium dome tweeter has arrived! Beryllium is known for its open and spatial sound, often described as holographic. The self damping properties of Beryllium allow for an extended response without a huge spike in the response at higher frequencies seen in most metal dome tweeters. All dome materials have a different tonal and spatial presentation. Beryllium has a real positive difference, providing a experience unlike all other dome materials.
Special Features:
- Beryllium dome for non-resonant high frequency extension
- Two part aluminium faceplate with integrated mechanical decoupling
- Dual balanced compression chambers for improved dynamics
- Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
- High saturation neodymium motor system with T-shaped pole piece for lower distortion
- Non-reflective cast aluminium chamber with optimized damping for improved dynamics
- Shallow flow optimized magnet structure for optimum coupling to rear chamber
- CCAW voice coil for low moving mass
- Long life silver lead wires
- Low resonance frequency for extended range
Beryllium is a toxic material. Should you ever break the dome, do not touch the pieces with your bare hand.
